Proving Ring
MODEL: QCC-048 TO 060
Specification: The Proving Rings are made of special steel, carefully forged to provide high and stable accuracy, dependability and repeatability. The dial gauge and anvil are mounted on U-brackets clamped to the ring body by set screws. The indicator has a sensitivity of 0.002mm/ div and the deflection is directly proportional to the applied load. The rings are supplied complete with dial gauge and Works Calibration Chart, individually packed in polished wooden boxes. NPL (India) / NCCBM Calibration Certificates can also be arranged for any proving ring at an additional cost. Separate Pair of Loading Pads are provided to suit each proving ring.
| Model | Capacity |
|---|---|
| Proving Ring Model QCC-048 | 25kgf to 100kgf (1KN) |
| Proving Ring Model QCC-049 | 200kgf (2KN) |
| Proving Ring Model QCC-050 | 250kgf (2.5KN) |
| Proving Ring Model QCC-051 | 1000kgf (10KN) |
| Proving Ring Model QCC-052 | 2000kgf (20KN) |
| Proving Ring Model QCC-053 | 2500kgf (25KN) |
| Proving Ring Model QCC-054 | 3000kgf (30KN) |
| Proving Ring Model QCC-055 | 5000kgf (50KN) |
| Proving Ring Model QCC-056 | 100KN (10Tons) |
| Proving Ring Model QCC-057 | 200KN (20Tons) |
| Proving Ring Model QCC-058 | 500KN (50Tons) |
| Proving Ring Model QCC-059 | 1000KN (100Tons) |
| Proving Ring Model QCC-060
Proving Ring Model QCC-061 |
2000KN (200Tons)
3000KN (300Tons) |
